Beiben NG80 Tipper/Dump Truck 6×4 2634KY
| Beiben NG80 Tipper/Dump Truck 6×4 2634KY | |
| Model | 2634KY |
| Engine | WEICHA WP10.340E32, 340HP, |
| Displacement | 9.726L |
| Transmission | 12JS160T gearbox, 10 forward, 2 reverse |
| Steering | ZF8098 hydraulic steering with power assistance |
| Clutch | GFX430, Single dry frictional disc, Hydraulic boosting |
| Front axle | 7.5T Double-shoe pneumatic brake, non-driving steering axle |
| Middle Rear axle | 13Ton Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle |
| Cab | NG80B short cab, inner A/C,no bed |
| Rim/Tires | 12.00R20radial tire (one spare tire) |
| Cargo box Dimensions | 5600x2300x1100+500mm |
| Thickness of Cargo box | 8 mmx6mm. |
| Overall Dimensions | 8347×2500×33840mm |
| Gross Vehicle Weight | 25000kg |
| Wheel base(mm) | 3800+1450mm |
| Color | white, Orange |
| Fuel Tank | 400L |
