| Beiben NG80 Tipper/Dump Truck 8×4 |
| Model |
3138K |
| Engine |
Weichai WP10.380E32, 380HP |
| Displacement |
9.726L |
| Transmission |
12JS200T gearbox, 12 forward, 2reverse |
| Steering |
ZF8098 hydraulic steering with power assistance |
| Clutch |
GFX430, Single dry frictional disc, Hydraulic boosting |
| Front axle |
Double-shoe pneumatic brake, non-driving steering axle |
| Middle Rear axle |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle |
| Cab |
NG80B short cab, inner A/C, no bed |
| Rim/Tires |
12.00R20radial tire (one spare tire) |
| Cargobox Dimensions |
7500x2300x1400mm |
| Thickness of Cargobox |
8mmx6mm |
| Overall Dimensions |
8120×2500×3430mm |
| Wheel base(mm) |
1500+4150+1450mm |
| Color |
white, yellow |
| Fuel Tank |
400L |
